10 kA Icu at 230...240 V AC 50/60 Hz conforming to EN/IEC 60947-2 4500 A Icn at 230/400 V AC 50/60 Hz conforming to EN 60898 3 kA Icu at 440 V AC 50/60 Hz conforming to EN/IEC 60947-2 5 kA Icu at 400...415 V AC 50/60 Hz conforming to EN/IEC 60947-2 10 kA Icu at 125 V DC 2P conforming to EN/IEC 60947-2 20 kA Icu at 125 V DC 3P conforming to EN/IEC 60947-2 25 kA Icu at <= 250 V DC 4P conforming to EN/IEC 60947-2
Suitability for isolation
Yes conforming to IEC 60947-2
Complementary
Network frequency
50/60 Hz
[Ue] rated operational voltage
440 V AC 50/60 Hz 400...415 V AC 50/60 Hz <= 250 V DC 230/400 V AC 50/60 Hz 230...240 V AC 50/60 Hz per pole
Magnetic tripping limit
5...10 x In
[Ics] rated service breaking capacity
7.5 kA conforming to EN/IEC 60947-2 - 230...240 V AC 50/60 Hz 2.25 kA conforming to EN/IEC 60947-2 - 440 V AC 50/60 Hz 3.75 kA conforming to EN/IEC 60947-2 - 400...415 V AC 50/60 Hz 4500 A conforming to EN 60898 - 230/400 V AC 50/60 Hz
Limitation class
3 conforming to EN/IEC 60947-2
Contact position indicator
Yes
Control type
Toggle
Local signalling
ON/OFF indication
Mounting mode
Clip-on
Mounting support
35 mm symmetrical DIN rail
Comb busbar and distribution block compatibility
NO
9 mm pitches
8
Height
81 mm
Width
72 mm
Depth
73 mm
Net weight
0.48 kg
Mechanical durability
20000 cycles
Connections - terminals
Tunnel type terminals16 mm² flexible Tunnel type terminals25 mm² rigid
