Schneider Electric 51327, Kondansatör - Varplus2 - 400/480V - hafif kirlenmiş şebeke - 9 kva

Name: Schneider Electric 51327, Kondansatör - Varplus2 - 400/480V - hafif kirlenmiş şebeke - 9 kva
Brand: Schneider
SKU: 51327
Price: 2622.96 TRY
Availability: InStock

Ürün Kodu: 51327

7.089,07 TL

2.622,96 TL

%63

Daha Fazla Devre Kesiciler

Adet

KoleksiyonFiyat Alarmı

Main
Range of product	Varplus²
Device short name	capacitor
Product or component type	Capacitor
Network frequency	50 Hz 60 Hz
Capacitor technology	3P capacitor
Reactive power rating	8 kvar for 415 V AC 60 Hz polluted 6.25 kvar for 400 V AC 50 Hz polluted 6.5 kvar for 415 V AC 50 Hz polluted 7.5 kvar for 400 V AC 60 Hz polluted 7 kvar for 415 V AC 50 Hz highly polluted 6.5 kvar for 400 V AC 50 Hz highly polluted 9.1 kvar for 440 V AC 60 Hz polluted 9.1 kvar for 440 V AC 60 Hz slightly polluted
Network rated voltage	440 V AC 60 Hz 400 V AC 50 Hz 415 V AC 50 Hz 400 V AC 60 Hz 415 V AC 60 Hz
Network pollution level	Polluted (15…25 %) at 440 V 60 Hz Slightly polluted (0…15 %) at 440 V 60 Hz Polluted (15…25 %) at 400 V 50/60 Hz Polluted (15…25 %) at 415 V 50/60 Hz Highly polluted with detuned reactor (25…50 %) at 400 V 50 Hz Highly polluted with detuned reactor (25…50 %) at 415 V 50 Hz
Tuning order	3.8 turning frequency: 190 Hz, impedance: 0,0692 50 Hz highly polluted 4.3 turning frequency: 215 Hz, impedance: 0,054 50 Hz highly polluted

Complementary
Capacitor protection	High current fault protection by HRC cartridge Low current fault protection by combination of single phase internal overpressure device with the HRC fuse
Capacitor voltage	480 V AC, 50 Hz 480 V AC, 60 Hz 480 V AC, 50 Hz with detuned reactor
Power losses	< 0.5 W/kVAr discharge resistors included
Capacitance tolerance	- 5 % to 10 %
Rated short-duration power frequency withstand voltage	4 kV 50 Hz 1 minute 4 kV 60 Hz 1 minute
[Uimp] rated impulse withstand voltage	15 kV 1.2/50 µs
Voltage test	2.15 x Un ( 10 s )
[Ures] residual voltage	50 V 1 minute with internally fitted discharge resistors
Maximum permissible voltage	1.1 x Un (8 hours over 24 hours) conforming to IEC 60831
[Imp] maximum permanent current	1.3 x I1 permanently conforming to IEC 60831
Type of installation	Indoor installation
Colour code	Base: RAL 7030 Cover: RAL 7030 Elements: RAL 9005
Connections - terminals	M8 rods3 cable(s)
Earth circuit	Not mandatory
Height	229.5 mm
Width	220.5 mm
Depth	97 mm
Product weight	2.1 kg

Environment
Standards	UL 810 IEC 60831-1 IEC 60831-2 CSA C22.2
Product certifications	CSA UL
IP degree of protection	IP00 without cover IP20 with protective cover IP42 with protective cover and cable glands
Temperature class	D
Ambient air temperature for operation	-25…55 °C
Average ambient air temperature for operation	35 °C (average over 1 year) 45 °C (average over 24 hours)
