Controller functionality |
Motion control, Sequence control |
Max. number of synchronous axes |
8 |
Max. number of axes (incl. virtual) |
15 |
Primary task cycle time |
0.5 ms |
Program memory |
5 MB |
Variables memory |
2.5 MB |
Communication port(s) |
EtherCAT Master, EtherNet/IP, USB |
Communication option(s) |
CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485 |
Max. number of remote I/O nodes |
192 |
I/O system |
CJ I/O Bus |
Max. number of expansion units |
40 |
Product Height (unpacked) |
96 mm |
Product Width (unpacked) |
90 mm |
Product Depth (unpacked) |
150 mm |
Product Weight (unpacked) |
530 g |
